Hello

I have some servers with Perc H310 RAID array controllers running RAID 5 VDs

I have added some extra disk in empty slots, but when I come to add them to the RAID, the Extend Drive option is greyed out.

Do I have to recreate the virtual drives???

Sponsor

Want to thank us? Use: Patreon or PayPal or Bitcoins: 12G4A52Znm5s35buKDEmKU2p2vQY69Nsyo

Protect your visitors with SSL, from $3.44

All opinions expressed within these pages are sent in by members of the public or by our staff in their spare time, and as such do not represent any opinion held by sircles.net Ltd or their partners.


sirclesadmin
2 years ago
If you download the AVAGO MegaRAID software from Lenovo, you can use this to expand the drive capacity with a new disk.

Backup first.

Now open AVAGO and right click the VD.

Choose reconfigure and choose RAID 5 as the configuration you are migrating to (I know, not very obvious)

Now you will get a screen showing the spare drive and you will be able to add the new drive into the VD group.

It will take some time to reconfigure but it is supported as an online drive extension feature.

UserPostedImage
